Description
Specification
|
Model No.
|
HP-RGBW50N60-5
|
||||
|
Power
|
15W/m
|
||||
|
PCB width
|
10mm
|
||||
|
Lumen output (RGBW, W=4000K)
|
Total 742 Lm/m CRI80+
442 Lm/m RGB
300 Lm/m CRI 80+
|
||||
|
MaxRun
|
5m | ||||
|
LEDs/m
|
5050 RGBW 60LEDs/m
|
||||
|
Cut Length
|
16.67mm(1LEDs)
|
||||
| CRI(White) |
White CRI 80+
|
||||
| CCT/Color |
RGB R:620-625nm G:520-525nm B: 465-470nm / White: 3000K, 4000K, 6000K
|
||||
| Voltage | 5V DC | ||||
| Dimmable |
Yes (SPI/DMX control system)
|
||||
| IP Rating | IP20 | ||||
|
Ambient temp.
|
-35°C ~ 50°C
|
||||
|
Beam Angle
|
120°
|
||||
|
Strip length/reel
|
0.5m ~ 50m
|
||||
|
Lifespan
|
50,000Hrs
|
||||
